Modbus TCP to Modbus RTU Gateway

Connect one or more Modbus RTU devices to a Modbus TCP Network

VS2

The VirtualSCADA® VS2 gives users the ability to connect a Modbus TCP master (e.g. PLC system) to one or more devices with a Modbus RTU connection. The transparent gateway will act as a Modbus TCP slave on an Ethernet network, transform the queries to the Serial Modbus network and send back the response to the Modbus TCP master. The gateway can be configured via it's internal webpage in a matter of minutes.

User Manual (PDF 2.09 MB)

Configuration Software (ZIP 0.98 MB)

Call us for pricing and delivery

Specifications

System Setup

Web-based user interface. Monitor Serial and Ethernet Communication Status

Network Porty

Ethernet Port: 10-100 MBit/s

Additional I/O

2 Digital Inputs (Isolated, max 24 V DC)

Antenna connector

SMA Female

Serial port #1

RS-232 (Screw Terminal and 9 Pin D Sub)

Serial port #2 (isolated)

RS-485

Serial baud rate

Up to 115.2 kbit/s

Protocols

Modbus-RTU

Type of housing

Enclosure Plastic / IP20

\DIN rail Mount

Yes

Dimensions

2.76" x 3.39" x 2.28" (70 mm x 86 mm x 58 mm)

Operating temperature

-40°F to+149°F ( -40°C to +65°C)

Power supply

9-24 V DC

Power consumption

1.7W

Certifications

CE
