Outdoor Rated SCADA Panel for Remote Access

Report Data from Modbus RTU, TCP and Ethernet/IP Devices with secure connection to remote industrial devices

SCADA Panel

The SCADA Panel is an NEMA-4X/IP65 outdoor rated panel consisting of a VS350 SCADA Server. The VS350 connects to industrial machinery via Modbus (serial), Ethernet, SNMP, EtherNet/IP or I/O and sends data to the cloud server via Ethernet or cellular communications. This VS350 will make it easy to collect data from a remote system, and securely get to cloud server. Data will be stored securely, with backup and redundancy of databases. It assures you that you can access your data when you need it. You can access the data through the web interface, with tools to build presentation pages using dashboard widgets. It makes it easy for you to focus on your business.

The VS350 is an advanced remote gateway that can handle many parameters both for logging and alarms with built-in GPS device to take control of the remote system’s position. By having communication redundancy data is garuanteed to be stored on our cloud server. The 3G communication provides increased performance compared to GPRS and also increases the geographical cellular coverage as it is possible to install the VS350 where 3G is the only available network. With support for 5 different 3G bands, the VS350 is a product suitable for the global market. The VS350 supports “Remote Access” functionality. This means that users can open up a secure connection to remote machinery and configure or operate it from any location using standard software applications. Remote access provides a secure data tunnel to the remotely located equipment.

For example, with a VS350 connected to a PLC, it is possible to perform remote debugging or programming of the PLC from any location, using the same PLC configuration software as usual. Configuration of the VS350 is done directly online via the cloud server. The cloud server is where your data can be monitored, analyzed or further processed (alarm routing, RSS, etc). The VS350 is a breeze to setup, No IT expertise required, No firewall issues, No VPN required, No static IP needed.

Brochure for Simplex Pump Systems (PDF 3.26 MB)

Brochure for Multiplex Pump Systems (PDF 3.45 MB)

Configuration Software (ZIP 0.98 MB) (For firmware version up to 1.6)

Our SCADA Servers work out of the box, not setup required, ready to go for your application.

Call us for pricing and delivery.

Application Brochures

Simplex Pumping

Multiplex Pumping

Irrigation

Heat Transfer

Ventilation

Oil & Gas

Material Handling

Water Wastwater

Specifications

3G/GSM/GPRS

3G: Five Band UMTS/HSPA+
(WCDMA/FDD)
(850/800, 900, 1900 and 2100 MHz)
GPRS: Quad-Band GPRS Class 12
(850/900/1800/1900 MHz)

Antenna

Integrated with Panel (External antenna available as option)

GPS

Built-in, requires GPS antenna (Option)

Serial port #1

RS-232

Serial port #2

RS-485

Serial baud rate

Up to 115,2 kbit/s

Digital Inputs

2 (Dry contact)

Analog Inputs

4, all supporting 0-10 V or 0-20 mA (2 supporting PT100)

Relay Output

1, (24V DC / 1A)

Protocols

Modbus-RTU ModbusASCII, SNMP, Modbus TCP, (EtherNet/IP during 2014)

Panel Material / Door

Plastic Polycarbonate

Wallmount

YES

Panel Dimensions

11.03 " x 8.66" x 3.93" (280x220x100 mm)

Operating temperature

14°F to +104°F / -10 to +40 °C

Power supply

100 - 240 VAC

Power consumption

4.5 W

Panel Certifications / SCADA Server

CE / CE (CULUS, FCC, IC, PTCRB. Telec, RCM ATEX/Haz.Loc pending)

Panel Rating

NEMA 4X / IP65

Ordering Part Number

VS350-SP
